Great Performance: 150+ Mbps real outdoor throughput and up to 15km+ range. The typical range is 2-4 miles from a LOS tower running airMAX sector antennas and Rocket M5s.

Next-Gen Antenna Design: 11dBi dual-polarity gain at 5GHz with optimized cross-polarity isolation in a compact form factor.

Dual Ethernet Connectivity: A secondary Ethernet port with software-enabled POE output for seamless IP Video integration.

Intelligent POE: Remote hardware reset circuitry of Nano Station M allows for the device to be reset remotely from the power supply location.

802.3af 48V Compliant – Easily becomes 802.3af 48V compliant through the use of Ubiquiti Instant 802.3af adapter.

The adapter is sold separately (SKU#I8023AF-OD or I8023AF-ID)

Easy Installation – Easily mountable to a pole/mast with mounting straps provided. In addition, the Nano Station M5 can be mounted and adjusted in any direction at a 90-degree angle through the use of the Nano Bracket. The Nano Bracket is sold separately (SKU#MT-NANO U)

Processor Specs: Atheros MIPS 24KC, 400MHz

• Wireless: 5Ghz Atheros, 27dBm Adjustable down to 8dBm, AES Encryption

• Memory Information: 32MB SDRAM, 8MB Flash

• Networking Interface: 2 X 10/100 BASE-TX (Cat. 5, RJ-45) Ethernet Interface, PoE Passthrough

• Mount and mounting strap (Nano bracket is optional, sold separately)

• Operating Temperature: -30C to +80C

• Power Method: Passive PoE

• Power Consumption: 8 Watts

• Power Supply (included): Power Injector 110-240VAC 24VDC .5A North American-style plug

• Size: 29.4 cm x 8 cm x 3cm, Weight: .4kg

• Approvals: FCC Part 15.247, IC RS210, CE

• RoHS Compliance: YES
